Supernova MKIV – The Standard for Power and Articulation
The Supernova MKIV Series epitomizes state-of-the-art subwoofer design. It delivers uncompromising performance and superior technology, combined with the world’s most refined low-frequency response. The MKIV sets a new standard in a class of its own.
While the selection of subwoofers is vast, the Supernova MKIV reigns supreme at the top. With more patented technologies and test awards than any other subwoofer, the MKIV continues the legacy of the legendary MKV series.
The MKIV differs from its predecessor by introducing the revolutionary IQ600 Class J amplifier and full DSP with phase and time control. Patented technologies such as Class J amplifier technology, Overdrive, ODL, SLAPS, DBXI, and Magma X define the MKIV’s groundbreaking performance.
If you desire uncompromising LFE performance with superb dynamics, effectiveness, and quick, precise articulation, the MKIV is the obvious choice. It effortlessly produces lower octaves in high-end stereo setups and adds explosive LFE effects in large surround sound systems.
The Supernova MKIV features a deep, luxurious black piano lacquer finish. The cabinet undergoes thorough sanding and priming, multiple layers of black lacquer with fine sanding between each, and is finished with a smooth, high-gloss clearcoat. This elegant piano lacquer complements its compact, modern design and adds sculptural finesse and exclusivity to your home.
Genuine Room Correction
Many manufacturers include some type of room correction in their subwoofers, mostly based on simple level adjustment via volume, which does not address phase and time-related challenges of a listening room.
The MKIV offers genuine room correction that accounts for reflections, refractions, arrival times, and EQ. This complete DSP solution ensures optimum acoustic integration in any room.
IQ600 Class J Amplifier
The MKIV’s brute force comes from the newly developed IQ600 Class J amplifier. The patented Class J technology represents a quantum leap in amplifier design, combining 99% efficiency with extraordinary bass control.
Class J evolves PWM technology by integrating advanced multi-level feedback with an intelligent controller. It modulates supply voltage and output switching frequency in real time based on the input signal’s frequency and amplitude. This intelligence increases thermal headroom, improves bass response, and enhances dynamic power.
The result is a harder, more impactful sound akin to live concerts, reproducing nuances and details often missed by traditional subwoofers.
Power Supply and Continuous Power
The IQ600 amplifier is powered by an oversized, rigid silicon-steel, hard-wound 750VA toroidal transformer ensuring stable voltage without drop during continuous heavy use.
It delivers 1200 watts continuous power at 18 dB crest factor and 600 watts TSP (True Sine Wave Power), representing real-world performance the woofer driver is designed to handle.
Overdrive System
Overdrive is a patented system that provides exceptional high dynamic output by constantly monitoring amplifier power resources and dynamically adjusting high-voltage supply.
It calculates power potential in real time, preventing distortion and protecting speakers while delivering peak power double the nominal IQ600 specification — up to 1200 watts program material.
Optical Distortion Limiting (ODL)
The patented ODL circuit fully protects against distortion without interrupting the audio signal path.
Using an optical coupler, the input signal is duplicated; one copy proceeds untouched to amplification, while the other is converted to light and compared with amplifier output. If distortion risk is detected, ODL adjusts input power instantly for distortion-free sound.
SLAPS Technology
SLAPS (Symmetrically Loaded Audio Passive System) dramatically increases subwoofer efficiency and ultra-low frequency capability.
Built symmetrically, SLAPS integrates identical suspension components to move identically in both directions. Pneumatic coupling between SLAPS and the active driver DBXI/MagmaX overcomes limitations of conventional closed or ported designs, allowing deep, dynamic, and hard-hitting bass without compression.
MAGMA Driver and TCT Technology
The MAGMA driver in the MKIV12 converts electrical energy into physical movement with superior mechanical construction, featuring heavily over-engineered components.
It incorporates patented TCT (Turbine Cooled Transducer) technology — a fixed turbine vane in the magnet gap that forces air to rotate in a vortex, dramatically increasing cooling efficiency.
The result is a 3 dB increase in sound output at rated power compared to similar transducers without TCT.
