Power input
110-240Vac/50-60Hz (EU/US Version)
IEC C14 power inlet, a fuse holder with power on/off switch plus two-stage EMI filter for low impedance load
with better noise attenuation in low frequency applications
Mains cable
UK
DC OUT cable
5×2.5mm DC plug / 5×2.1mm DC plug
Custom cables made to order at additional cost
Output Voltage Range
5-30 [V]
Max Continuous Output Current (for V_out below 10V)
6 [A]
Max Continuous Output Current (for V_out higher than 10V)
l_out= 60[W] / DCout[V]
Max Continuous Output Power (for V_out below 10V)
P_out = V_out[V] * 6[A]
Max Continuous Output Power (for V_out higher than 10V)
60W
Dimensions (without knob, feet and connectors) (W x D x H , mm / inches)
217.5 x 206.5 x 50.0 / 8.6 x 8.1 x 2.0
Net weight (kg / lb)
~ 2,8 / ~ 6.2
Primary winding fuse
IEC 5x20mm fuse, 3.15AT, 250V
Secondary winding fuse
Littelfuse 154004T, 4A
Power consumption (idle)
TBD
